1.5 tons Electric Forklift Truck
1.5Tons Diesel Forklift Truck
Main Features :
- Max. Lifting capacity : 1500kg 1.5Ton
- Max. Lifting height : 3000mm
- Power Type : Diesel
- With CE cetificate
- Good Quality and high working efficient
| Model | SH15J | |
| Load capacity | 1500 kg | |
| Load center | 500 mm | |
| Power type | Battery | |
| Max. lifting speeds (with load) | 285 mm/s | |
| Max. driving speeds (with/without load) | 12/13.5 km/h | |
| Max. towing (with load) | 6.5 kn | |
| Gradeability (with load) | 15% | |
| Lifting height | 3000 mm | |
| Free lift | 60 mm | |
| Tilting angles (forward/ backward) | 6º/12º | |
| Min. turing radius | 1900 mm | |
| Min. right angle aisle width | 1890 mm | |
| Min. under-clearance | 95 mm | |
| Dimensions | Overall length (including fork) | 3040 mm |
| Overall width | 1086 mm | |
| Overall height (mast lowered) | 1995mm | |
| Overall height (mast extended) | 4000 mm | |
| Overall height to overhead guard | 2130mm | |
| Fork width | 100 mm | |
| Fork thickness | 35 mm | |
| Fork length | 920 mm | |
| Fork overhang | 430 mm | |
| Wheel base | 1300 mm | |
| Tread | Front tread | 900 mm |
| Rear tread | 920 mm | |
| Tyre | Front tyre | 6.50-10 |
| Rear tyre | 5.00-8 | |
| Total weight | 3050 kg | |
| Motor | Traction motor | JXQ-8 |
| Lifting motor | XQD-7.5 | |
| Battery | Battery type | 24-DA-440 |
| Battery voltage/ Capacity | 48/440 V/Ah | |
Q:How to transport the truck?
A:We mainly transport it by ro-ro ship or bulk ship.
Q:I want to transport the truck by container, is it ok?
A:Yes, it is ok .But we need take apart the truck.You should reinstall in your country.
Q:How about your product quality?
A:All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q:What is the payment term?
A:Now the payment term we can accept is by T/T or L/C.
Q:Can you provide after-sale service?
A:Yes,of course,no matter it’s truck,construction machinery or spare parts,once we sell that to customers,we can provide after-sale service for customers,it means that if our products have related problems,just contact with us,we will try to solve that for customers and give the customers satisfied reply,since we are looking forward to long-term stable cooperation with customers.
